Low Volume PCB Assembly

Mer-Mar Electronics specializes in low volume PCB assembly with customized features. We provide complete turnkey low volume PCB assembly wherein we take care of the entire PCB assembly – fabrication, component mounting, assembly, testing, and delivery. With our skilled engineers and dedicated workforce, we are well-equipped for small batch PCB assembly that can be delivered in the shortest lead time.

As a leading small batch PCB manufacturer, we are equipped with advanced manufacturing facilities and capabilities to handle the customer’s quality expectations and get the project done in a quick turnaround time. By deploying the techniques like Design for Manufacturing (DFM) and Design for Testing (DFT) in the process, we make sure to identify any problems and optimize before going to final production.

We are also an ISO 9001:2015 certified company since 1999 with IPC trained personnel and Triple Processes Inspection adhering to the highest quality standards for small batch PCB assembly requirements. Our meticulous QA team also relies on other testing and inspection services like optical inspection, X-ray testing, etc. All the small batch PCB assembly are manufactured with specialized support, reliability testing, and authorized workmanship.

Cutting-edge Low Volume PCB Assembly Solutions

High Precision – Known for creating high-precision low volume circuit board assemblies in a neat and orderly manner with properly maintained and latest equipment. We have a highly experienced team who stringently pays attention to attain the level of accuracy and precision required.

Top-notch Quality – For us, quality is never an accident. We put in all the assembly lines in such a way that our component procurement and small PCB assemblies are in line with your company’s goals and requirements.

High-Yield Rate – We ensure a high yield rate while preventing any common PCB assembly faults and identifying the potential problems beforehand. Through DFM checks, we cut the manufacturing costs and eliminate any unforeseen expenses.

Unmatched Reliability – By deploying the right technique, we improve your circuit board’s ability to withstand any mechanical or environmental stress like high temperatures. Your low volume PCBs would have high heat tolerance to be used in aerospace and defense.

Streamlined Processes – We follow well-documented process controls in accordance with ISO regulations for risk management, traceability, and quality controls. We also govern the quality of the manufacturing operations through cleanliness standards and improving the shelf life.

Low Volume PCB Assembly

Low Volume PCB Assembly Services

Low Volume PCB Assembly

Design for Manufacturing

Our DFM services are meant to avoid any delays in the engineering process that may hamper the fabrication process and fasten up the delivery. We thoroughly scrutinize the customer documents like Bill of Materials (BOM), Gerber files, assembly drawings, and circuit drawings. We also examine the components list before we order them and go for only those solder masks that obtain high output rates.

PCB Assembly Low Volume

Design for Testing

Our shrewd quality assurance team readily identifies the test points on your printed circuit boards to help you decide on the fixtures, probe kinds, and understand any sort of limitations of your testing procedures. The expert knowledge in combination with our professional support process helps you identify the functionality of diagnostic instructions, testing requirements, problem identification procedures, and other references that are functional.

Small Batch PCB Assembly

Complete Turnkey Low Volume PCB Assembly

Every aspect of your project from PCB component procurement, fabrication, and assembly is handled by us efficiently without any compromise on quality. We are a single-source PCB manufacturing company that caters to all your needs from component sourcing to PCB fabrication to Test and quality control till it goes for packing and shipping. We go to great lengths to pay the same attention to low volume assembly runs as we do for high-volume projects.

Small Batch Printed Circuit Board

High Mix Assembly

With an upward trend in customization in the manufacturing environment, we have been focusing on efficiently and effectively managing high-mix assembly operations. We adopted the new tools and platforms for manufacturing high mix assembly operations that can react to the changes in the marketplace faster and keep up with the quality expectations. Our engineering team immediately modifies low volume PCB assembly processes quickly as product variations can be made easily.

Small Batch PCB Manufacturer

BGA and Micro BGA Assembly

We have a wealth of experience in handling both BGA and Micro BGA assembly on your PCB. We have been providing BGA and micro BGA assembly services with our state-of-the-art BGA placement equipment. We go for cutting-edge X-ray inspection equipment, high-precision BGA and micro BGA assembly processes for creating highly customizable PCB assembly solutions. You can count on us to build high-quality and high yield BGA and Micro BGA boards.

Low Volume Printed Circuit Board

Electronic Component Assembly

We are well-known for low volume electronics assembly and our products are highly demanded in the market. They are done under the supervision of our highly experienced and qualified professionals. Our electronic component assembly process involves solder paste stencil, placement, reflow, manual assembly, inspecting, and testing. These components assembly even comes in a compact design with reliable performance and durable standards.

Small Batch PCB

PCB Fabrication Parts Procurement

We procure parts from only authorized and leading distributors of electronic components. With years of experience in circuit assembly, we have built strong cooperative relations with authorized distributors. We ensure the PCB fabrication parts’ durability, quality, and performance and empower your circuit boards with the best possible functions. We have improved our low-cost PCB fabrication production line efficiency to get quality components to you.

PCB Small Batch

Soldering, Testing & Quality Control

The quality of solder joints rests with Mer-Mar Electronics. We are committed to quality and the process we follow is a reflection of that. We employ different testing methods like AOI, X-ray Inspection for solder joint quality, and a lot of other types of tests employed during the board’s assembly. We can also go for manual visual inspection to help you quickly assess the success of your low volume PCB assembly. We provide low volume PCB assembly in a cost-effective manner and quick turnaround time.

– 01

Low Volume PCB Assembly Capabilities

Supported Capabilities
Assembly Types Surface Mount (SMT), Thru-hole, Mixed Technology (SMT/Thru-hole), Single and double-sided SMT/PTH, complex circuit on one side, BGA on both sides
Stencils Laser-cut stainless-steel stencils
Components Passive components smallest size 0201, Fine pitch components smallest size 8 Mils pitch, Leadless chip carriers/ BGA, VFBGA, FPGA & DFN, Connectors and terminals
Inspection X-ray analysis, AOI, and Microscope to 20X
Solder Type Leaded and Lead-free/RoHS compliant
Shape Rectangular, Circular, Slots and cut-outs, and any Odd Shapes as per requirements
Board Type Flex, Rigid, Rigid-flex
Minimum Order No Minimum Order
Component Size Smallest Components, BGA, Micro BGA, and Fine Pitch Parts Assembly
Testing Flying Probe testing, ICT Testing, Automated Optical Inspection (AOI), Functional Testing, X-ray Inspection

– 02

Low Volume PCB Assembly Technologies

For the small volume PCB assembly process, we use three different technologies –

  1. Through-hole Mounting
  2. Surface Mount Technology
  3. Mixed Technology

Through-hole Mounting – While we opt for this method for low volume PCB assembly, our designers place the requisite components in the holes drilled on the board. Although an old-school technology, we make the best use of this technique. Especially for industrial applications in aerospace, we make use of this technique to make your circuit boards withstand high levels of stress and operate at high speeds and temperatures. We make sure the bond between the circuit and its components is stronger and hence you can have a reliable product that provides a high level of efficiency for your operations.

Surface Mount Technology – Our purpose to go for the SMT technique is to improve the quality as well as performance. As we mount the components onto the surface of PCBs, we offer tremendous flexibility, and more importantly, even the complex circuits can be done into small assemblies. Even the smallest of the components can be mounted by using contact terminals instead of leads. Also, we meticulously build dual-sided circuit boards with all the components on one side and complex circuitry on the other side. Through the automation process, we build highly customizable circuit boards for almost any application.

Mixed Technology – We use the properties of SMT and through-hole whenever necessary. We are a reliable small batch PCB manufacturer and well-equipped with the capabilities of both SMT and THT for manufacturing circuit boards. We can provide quick prototypes and even go for high-speed production. We have advanced and precise equipment to place the component of miniature size with great accuracy. You can have custom assemblies that are built by following the best practices in the industry.

– 03

Low Volume PCB Assembly Testing Methods

We have been pushing our limits when it comes to quality assurance. Irrespective of the batch size, we make sure that every circuit board that gets shipped from our company adheres to the same quality levels and intact functionality. We follow rigorous quality controls as we put in our efforts to deliver top-notch quality boards. We put in extra efforts to make sure that your low volume PCB assemblies do not have any errors and work with high precision.

We perform DFM and DFA checks for issue detection and anything that negatively impacts the low volume PCB fabrication process. We do conduct functional testing and see that the assembled boards are in line with your requirements. We employ advanced testing tools and equipment to ensure that components are perfect and see if any component needs repairs or replaced.

Tests we perform on your low volume PCB assembly –

  1. Functional Testing
  2. Manual Visual Inspection
  3. Automated Optical Inspection
  4. X-ray Inspection
  5. In-circuit Testing
  6. Fly-probe Testing

– 04

Industrial Applications of Low Volume PCB Assembly

With our printed circuit board assembly capabilities, we offer highly reliable services with the best combination of faster time-to-market and competitive pricing. Our steadfast commitment to quality assurance has gained us a vast customer base from the following markets –

  1. Aerospace
  2. Automobile
  3. Defense & Military
  4. Medical
  5. Semiconductor
  6. Telecommunication
  7. Electronics and Electrical
  8. Military

– 05

Certifications

ISO 9001:20015 Logo Itar Logo
  1. ISO 9001:2015
  2. IPC-CC-830B compliant
  3. IPC-WHMA-A-610 compliant
  4. IPC-A-610-D
  5. IPC 610 and IPC 600
  6. ANSI/J-STD-001
  7. RoHS compliant
  8. ITAR compliant

Low Volume PCB Assembly FAQs

Are you looking for low volume PCB assembly, small batch PCB Assembly, small volume PCB assembly, low-cost PCB assembly production or any custom PCB assembly for your Next project? Send us inquiry to Get a Quick Quote based on your custom requirements.

If you have any queries regarding to our low volume PCB assembly or need an urgent assistance, then please don’t hesitate to contact our team of skilled personnel’s. Send us an email with your queries at sales@mermarinc.com or call us at (760) 244-6149. We are looking forward to hearing from you.
