Mer-Mar is continually investing in capital that improves efficiency and insures quality. Most recently Mer-Mar added fourth generation Automated Optical Inspection (AOI) equipment. Mer-Mar also has added a dedicated flow solder line for lead free (RoHS) assemblies to complement the lead-free surface mount line that has been operating for years.

A list of our major pieces of equipment includes:

Automatic Pick & Place

Juki machine

01

Juki JX-100 SMT Pick & Place Machine

6 heads with laser alignment, 14,400 components per hour small chip 8mm or less
Placement points per program 2,000

Applicable Component Sizes: Height: min: 0.3mm max: 6mm
Size: min: 0.75 x 0.5mm max: 33.5mm sq
Lead Pitch: 15 mil
Applicable PCB Size: min: X 50mm x Y 30mm
max: X 330mm x Y 250mm
thickness min: 0.4mm max: 4mm
Zevatech FS machine

02

Zevatech FS-750 SMT Pick & Place Machine

3 heads with laser alignment, 8,000 components per hour small chip 8mm or less
Placement points per program 2,000

Applicable Component Sizes: Height: min: 0.3mm max: 6mm
Size: min: 1.0 x 0.5mm max: 23.5mm sq
Lead Pitch: 15 mil
Applicable PCB Size: min: X 50mm x Y 30mm
max: X 330mm x Y 250mm
thickness min: 0.4mm max: 4mm
Zevatech pm machine

03

Zevatech PM-570 SMT Pick & Place Machine

Single head with laser alignment, 3870 components per hour max rating
Placement points per program 2,000

Applicable Component Sizes: Height: max 6mm
Size: min 1.0 x 0.5mm max: 33.5 sq
Lead Pitch: 15 mil
Applicable PCB Size: min: X 30mm x Y 30mm
max: X 406mm x Y 330mm
thickness min: 0.6mm max: 2.5mm

Reflow Oven

heller reflow oven

01

Heller 1707EXL Forced Convection Reflow Oven

7 heating zones, 14 independent temperature controls
Complete computer control system with KIC & ECD software
3 Thermocouple Real Time profiling, Edge Hold Conveyor system

Process Tunnel: length: 72” (182.88cm)
width: 22” (55.88cm) usable 20” (50.80cm)
height: 2.625” (6.67cm)
Cooling Area: length: 15” (38.1cm) internal
Operating Range: 50-350 degrees centigrade
abw reflow oven

02

ABW Zoned Convection Reflow Oven

3 zones, 5 temperature controls
Conveyor speed 2-20 in/min

Process Tunnel: length: 42” (106.68cm)
width: 17.75” (45.09cm) usable 16” (40.64cm)
height: 1.5” (3.81cm)
Cooling Area: length: 12” (30.48cm)
Operating Range: 50-350 degrees centigrade

Wave solder

wave solder

Automatic wave solder system with proven performance, self-contained fluxing, preheating and laminar (smooth) solder wave modules. Decrease labor costs by significantly reducing hand soldering.

The Spartan 12S (Single wave) and 12D (dual wave) solder machines can process printed circuit board assemblies up to 12″ wide and require very little solder for their size. The single or dual wave soldering systems come complete with Conveyor, Foam Fluxer with Integral Air Compressor, Preheaters, and Stainless Steel Solder Pot with drain valve, and compact microprocessor Controller.

Washing Machine with DI water

This Fully Automatic Deionized Water Washing Machine is ideal for precise washing task like removal of ion contamination and particles. This exhibits high washing performance when it comes to items that require a high degree of cleanliness, such as HDD parts, glass, BGA and CSP substrates.
Features and uses:

  • Compact in size as a space-saving consideration with clean room use in mind.
  • Used for high-speed, large-capacity automated units to manual units geared for small-lot jobs
  • Offer Uniform and Stable Washing Quality

X-Ray Machine

x-ray machine

We have Photon Dynamics Superior X-ray (SX) Series which provides high-resolution and high magnification X-ray inspection capability in a flexible and compact workstation configuration. With its wide selection of X-ray sources, image intensifiers, sample manipulators and software, the SX Series is made specifically to meet the special non-destructive inspection requirements for today’s production, research development and quality assurance departments.

The Quality equipments are equipped with Photon Dynamics’ own RTI-580 image processing system, made for processing real-time X-ray images. Powerful and easy to use, RTI imaging systems provide repeatable and accurate results for both production and research applications.

AOI Machine

nordson

Nordson Yestech BX AOI system

BX AOI offers off-line benchtop PCB inspection with exceptional defect coverage. This benchtop system inspects solder joints and verifies correct part assembly enabling users to improve quality and increase throughput.

Benchtop Automated Optical Inspection

  • 5 megapixel color imaging
  • 1 top-down & 4 side angle cameras
  • Quick set-up
  • High speed
  • High defect coverage
  • Low false failure rate

Temperature Chamber

Thermotron SE 300

Quality is at the heart of Mer-Mar. We use Thermotron’s SE-300-2-2 temperature chamber, also known as environmental chamber to ensure high performance, high quality, higher productivity and accurate test results. SE-300-2-2 temperature chamber is equipped with Thermotron’s patented modular humidity system for simultaneous temperature and humidity testing.

SE-300-2-2 Technical Information:

  • I.D. 24″W X 26″D X 28″H
  • O.D. 38″W X 67″D X 77″H
  • Temperature Range: -70 to +170 Deg. C (Air Cooled)
  • Thermotron #8800 Touchscreen Control
  • Over and Under Temperature Protection
  • Environmentally Friendly Refrigerants, Stainless Steel Interior
  • 2X 4″ Dia. Side Feed-Thru Ports
  • Power: 230V, 3Ph, 70 Amps
pcb box build

Expert in frame integration projects and offering tailor-made PCB box build and system assembly services with its fully integrated advanced technologies.

turnkey

Full or partial turnkey assembly wherein all the inputs needed in the PCB manufacturing taken as per the specifications in the BOM and Gerber File.

electro mechanical assembly

Electro-mechanical services involve Flex circuit assembly, cable assembly or mechanical enclosures through to final ‘retail ready’ products.
