Mermar Electronics has many years of experience in manufacturing impedance control PCB. As the requirements for quick signal speeds in circuit boards rise, there is an added need to work on ensuring the best signal integrity. One of the areas that requires focus in design is controlled impedance traces. There needs to be a carefully created trace structure that ensures there aren’t any differences in impedance that can distort the signal. Matching the impedance of PCB traces, therefore, is important as it helps maintain data integrity as well as signal clarity.

Essentially, controlled impedance refers to the matching of substrate material properties with trace dimensions and locations. This ensures that the impedance of a trace’s signal is within an acceptable range.

Controlled impedance boards offer high frequency performance. If, on the other hand, the impedance of the PCB trace connecting two components does not match the components’ characteristic impedance, there may be an increase in switching times within the device or the circuit.

Typically, PCB trace impedance can range from 25 to 125 ohms. The impedance value generated from the PCB structure is determined by the following factors:

  • Width and thickness of the copper signal trace.
  • Thickness of the core or prepreg material.
  • Dielectric constant of the core and prepreg material.
  • Distance from other copper features.

At Mer-Mar Electronics, we have over 40 years of experience in offering high quality PCBs. Armed with state-of the-art technology, experienced professionals and industry best practices, we ensure that the trace impedances and their tolerances are checked early on in the design since uncontrolled impedance is difficult to analyze once the components are mounted on the circuit.

Our controlled impedance PCB design and manufacturing services ensure that you do not have to face any issues when it comes to signal integrity. We work with your team at the PCB design stage itself to help you control impedance by selecting the right material as well as layer stack up.

Our controlled Impedance PCBs are manufactured using the latest material as well as technology. We also undertake stringent Incoming Inspection for laminates, prepreg and copper foil.

The use of LDI (laser direct imaging) equipment eliminates any variances in trace width. The etch process is smoothly managed to make sure that we meet the impedance tolerance limits.

You can rest assured that we conduct robust tests to ensure that we achieve the desired impedance using TDR coupons.

Mer-Mar Electronics – Your Reliable Partner for
Controlled Impedance PCBs

Superior facility –

We have state-of-the-art facilities that ensure that controlled impedance PCBs are manufactured using the latest material and technology.

Experienced Personnel –

Our trained personnel are fully equipped with industry best practices to ensure that the impedance tolerance limits are adhered to. We offer both design and manufacturing expertise when it comes to Controlled Impedance PCBs.

Quick Turnaround –

At Mer-Mar Electronics, we ensure that we offer fast turnaround without compromising on the controlled impedance tolerances.

Desired Quantities –

You can count on us to offer the quantities desired by you. What that means is that you do not have to worry either about minimum orders or large production runs.

Impedance Control PCB

Impedance Control PCB Services

Impedance Control PCB Design

Impedance Control PCB Design

Impedance-controlled routing begins with the schematic. While design engineers specify their controlled impedance signals’ values and types, we use your design data and manufacturing drawings, as well as our DFM tools and experience, to validate your design against the requested board materials. We work with you to ensure that the target impedance values are within the specified range.

To ensure that the same impedance values are maintained throughout the length of a controlled trace, we take into account the following parameters:

  • Trace geometry
  • Signal spacing
  • Dielectric material
Controlled Impedance PCB

Impedance Control PCB Manufacturing & Testing

Having validated the design, we manufacture the board, getting as close as possible to the target impedance. We also undertake extensive TDR testing to determine that the impedance is within the specified limits. Essentially, a TDR applies a quick electrical step signal to the coupon via a controlled impedance cable and a specialized probe to connect to the pads. If there is a change in impedance value, part of the signal power is reflected back to the TDR instrument. The time delay between the transmitted pulse and the receipt of the reflected signal is proportional to the distance of the discontinuity.

Impedance Control PCB Manufacturing

Types of Impedance Control PCB

Single Sided, double sided impedance control PCB, multi layered controlled impedance PCB, 8-layer, 6 layer, ENIG impedance control PCB, 4-layer, 6-layer, 8-layer OSP impedance control PCB, and more.

– 01

Impedance Control PCB Capabilities

With an experienced engineering staff, we analyze your design holistically. We take into account a wide range of factors when it comes to the design of controlled impedance PCBs. These include:

  • Inductance
  • Capacitive Resistance
  • Conductance

Additionally, you can count on us for the following:

  • Stack-up and impedance control calculation suggestions
  • Routing single-ended and differential pair traces.
  • Placing components, vias, coupling capacitors.
  • Calculating effective dielectric constant.
  • Delivering the required impedance tolerance.
  • Impedance Control PCB Prototype services
  • No minimum controlled impedance PCB order requirement.

– 02

Impedance Control PCB Process

Count on our experts to guide you on parameters such as the following, to achieve the required impedance:

  • Track width
  • Copper layer spacing
  • Copper weights
  • Base material

We use industry-leading software to assist with impedance calculations as well as the selection of appropriate PCB construction.

Additionally, we design suitable test coupons to verify calculated impedance with actual product outcomes using TDR measurement instruments.

– 03

Impedance Control PCB Applications

Increasingly more and more PCBs used in fast digital applications need to be impedance controlled. These include:

  1. Telecommunications
  2. Video Signal Processing
  3. Real time graphic processing
  4. High Speed digital processing

You will find numerous applications of the above in:

  • Routers
  • Satellite TVs
  • Personal Computers
  • Laser Printers
  • GPS navigation tools, and more

– 04

Certifications

ISO 9001:20015 Logo Itar Logo

We follow the requisite industry standards like

  • ISO 9001:2008 Certification
  • IPC-WHMA-A-610 Compliant
  • IPC-CC-830B Compliant
  • SBA Certified
  • IPC-A-610-D & ANSI/J-STD-001 standards
  • ISO 9001: 2015 Certified
  • ISO 13485: 2016 by Medical Devices Quality Management
  • International Traffic in Arms Regulation Compliant (ITAR)

Impedance Control PCB FAQs

Are you looking for impedance control PCB from Mer-Mar Electronics? Send us inquiry to Get a quick impedance control PCB quote based on your custom requirements.

If you have any queries regarding impedance control PCB, controlled impedance printed circuit board assembly, custom impedance control PCB assembly, industrial PCB fabrication, or need an urgent assistance, then please don’t hesitate to contact our team of skilled personnel. Send us an email with your queries at sales@mermarinc.com or call us at (760) 244-6149. We are looking forward to hearing from you.
