Lead Free PCB Assembly Services
Our Lead-Free Assembly Services Include
Lead free Material Analysis
With stringent regulation of hazardous components that cannot be used in either the boards, components, or solders, material analysis acquires a major role. Our trained team is totally equipped to undertake a thorough analysis of the material to ensure that it can be used.
Lead free Assembly (SMT or THA)
We undertake a stringent assembly process, both SMT and THA, adhering to RoHS standards. With extensive inspection and testing built into the process, you can be sure of receiving a high-quality product.
Lead Free Wave Soldering
Our wave soldering lines catering to multiple sizes ensure that we can accurately solder the board for circuit board assemblies containing through-hole parts. The right temperature and stable solder wave height ensures there is no cracking, loss of conductivity or mechanical stress on the board.
Lead free Circuit board rework
Rework is an important aspect of the volume manufacturing process for lead-free PCB assembly, both during the initial transition period as well as the product lifecycle. We are equipped to take on this highly specialized work that offers reliable lead-free solder joints, with proper grain structures and intermetallic formation. All rework performed uses the same lead-free solder alloy as originally used on the solder joint.
Lead Free PCB Assembly Process
To ensure that the PCB assembly is lead free, it is important that due attention be paid to several aspects including but not limited to ensuring that none of the hazardous materials listed in the RoHS directive are used either in the boards, components or solders. It is also important that the finish on the board be compliant with lead-free and RoHS standards. Since the boards are required to be assembled at high temperatures, the various components need to be able to withstand these high temperatures. The overall lead-free PCB Assembly process involves the following steps:
1. Profiling
Oven reflows temperature profiling demands that an additional lead-free PCB along with an extra set of temperature critical parts such as BGAs, heat slug parts etc. be provided. Mechanical Samples also work well for this purpose.
2. Inspection
With our inspection staff trained to IPC-610D standards, we ensure that the solder joints are of high quality.
3. Bill-of-Materials and Component Analysis
While the customer needs to verify the bill-of-materials to ensure the suitability for lead-free parts, we offer a detailed consultation to ensure that the components meet the requirements. In case the components received, suffer from excess moisture issues, they are baked, prior to assembly.
4. Board Stencil and Solder Paste
This process involves application of SAC305, a lead-free compatible solder paste that is widely used in SMT, Wave Solder and Wire (Hand) Soldering processes. Post the soldering process is over, a thorough visual inspection is done to make sure that the solder coverage is accurate.
5. Placement of Components
Next, a pick-and-place machine ensures that parts are accurately placed. With a unique number assigned to each part, it is ensured that the right part is being placed. Of course, it is ensured that all components on the board are lead-free process compatible and can withstand high temperature.
6. Through Hole and Manual Solder
We are well equipped to perform Through Hole and Hand / Wire soldering of lead-free boards.
7. Placing Board in the Reflow Oven
As a final step, the board is placed in the reflow oven where the solder paste enables the component and the circuit board to form a bond. The thermal profiling is done keeping in mind the following characteristics:
- Thickness of board
- Board Finish
- Board Size
- Layer Count
8. Testing
A visual inspection ensures that any manufacturing defects are brought to light. The use of IPC 610D soldering acceptability standard ensures that testing is robust.
9. Packaging
The assembled boards are then packed for shipment.
